IMPELLER
MAIN DIMENSIONS
Outer diameter: 3″ 3/4 (95 mm)
Depth: 2″ 1/2 (63 mm)
Profile and blades nr.: type O with 9 blades
Insert material: brass
Shaft diameter: 1″ (25.4 mm)
Spline Drive
Replaces:
Jabsco P/N: 836-0001, 83600-0001, 836-0001P
Johnson P/N: 09-1029B
KASHIAMA P/N: KP-220 / SP200
NK P/N: F40CBC
CEF P/N: CEF500105
Volvo P/N: 875636 / 807904 / 875660 / 21951360 / 21730344
Cummins P/N: 160596 / 166758 / 556540
Vetus P/N: IMP00901
JMP P/N: 8000-01
